• APPLICATION

    Hidden fastening system that provides a secure face-fastened connection with precision cut plugs made from actual PVC trim boards. Installation is a two-step process utilizing a setting tool, screws and plugs. All components must be used together as instructed to ensure proper function.

  • FEATURES

    • Plugs are for 5/8″ to 1-1/4″ thick PVC trim and available in all leading brands
    • Available in Kits (screws, plugs and tool) and Inventory Management (system components sold separately)
    • Patented PVC/Composite Tool with Auto-Stop™ sets screw to the correct depth without stripping screw recess
    • Free spinning stop collar on setting tool prevents damage to the board surface
    • Screws feature a Type 17 auger tips for faster, easier insertion and to help prevent splitting

  • INSTALLATION

    Follow all PVC trim manufacturer instructions, including specifications for screw spacing, edge/end distances, and gapping.

    • Retrieving data. Wait a few seconds and try to cut or copy again.
    • Drive the screw with the PVC/Composite Tool using a standard drill on high speed.
    • Do not use impact driver with setting tool.
    • The setting tool’s Auto-Stop™ mechanism will make a “pop” sound when the screw is set to the correct depth. (Do not hesitate or slow down while driving.)
    • Insert plug into hole and tap with a smooth-faced hammer until the plug is flush with board.

  • Install screw with PVC/Composite Tool. Insert plug and tap with smooth-faced hammer.

  • For use with Impact Driver. Built in Magnet. Insert plug and tap with smooth-faced hammer.

PLUGS AVAILABLE IN THE FOLLOWING BRANDS

AZEK®
BETTER BRAND®
BORAL®
CERTATRIM®
INTEPLAST®
KLEER®
KOMA®
NUCEDAR®
SKYTRIM®
PLY GEM®
ROYAL®
RESTORATION MILLWORK®
VERSATEX®
WOLF
XO™

New board brands are always being added to our product offering. Please refer to our website or contact
Starborn® customer service if you do not see the board brand you are looking to use on your project.

SYSTEM COMPONENTS

  • PVC/Composite Tool For setting screws to the correct depth

  • Screws Epoxy coated, grade 305 or marine grade 316 stainless, or epoxy coated grade 410 stainless for metal framing

  • Plugs Made from actual PVC/ Composite decking and trim material

  • Impact Driver Bit For use with impact drills

  • PRO PLUG® SYSTEM TRIM PACKAGING

    KIT PACKAGING
    LENGTH FINISH COVERAGE SCREWS PLUGS TOOL
    2″ Epoxy 50 If 75 85 –
    250 If 375 400 1
    750 If 1125 1200 1
    2-3/4″ 50 If 75 85 –
    250 If 375 400 1
    750 If 1125 1200 1
    2″ 305 Stainless 50 If 75 85 –
    250 If 375 400 1
    750 If 1125 1200 1
    2-1/2″ 50 If 75 85 –
    250 If 375 400 –
    750 If 1125 1200 1
  • INVENTORY MANAGEMENT-PLUGS ONLY
    PLUGS COVERAGE
    100 –
    400 250 If
    1200 750 If
  • INVENTORY MANAGEMENT-SCREWS ONLY
    LENGTH FINISH SCREWS COVERAGE
    2″ Epoxy 100 –
    375 100 sq ft
    1125 300 sq ft
    2-3/4″ 100 –
    375 100 sq ft
    1125 300 sq ft
    3″ 100 –
    375 100 sq ft
    1125 300 sq ft
    2″ 305 Stainless 100 –
    375 100 sq ft
    1125 300 sq ft
    2-1/2″ 100 –
    375 100 sq ft
    1125 300 sq ft
    3″ 100 –
    375 100 sq ft
    1125 300 sq ft
    2-1/2″ 316 Stainless 100 –
    375 100 sq ft
    1125 300 sq ft
    3″ 100 –
    375 100 sq ft
    1125 300 sq ft

FINISH

Epoxy coated
Grade 305 Stainless
Grade 316 Stainless

CORROSION

Exterior Use

Approved for use in ACQ and pressure treated lumber.

For salt water or other areas where corrosion is a concern, use Grade 316 Stainless.

DRIVE SYSTEM

Star Drive

TOOL COMPATIBILITY

PVC/Composite Tool
PVC/Composite TRIM Bits
